Since its promulgation in 1971 by the National Highway Traffic Safety Administration (NHTSA), FMVSS 302 has become a globally recognized fire test standard in the automotive industry. Its core objective is to extend passenger escape time and reduce fire injuries by controlling material burn rates. The standard applies to interior materials of passenger cars, trucks最安全的杠杆炒股平台官网, buses, and other vehicle types, covering nearly 20 components including seats, roof liners, floor coverings, and sun visors.

展开剩余76%

FMVSS 302 Test Requirements

· Burn Rate Limit: Horizontal flame spread rate shall not exceed 102 mm/min.

· Burn Time & Damage Length: Material passes if flames self-extinguish within 60 seconds with damage length ≤51 mm (measured from 38 mm mark at ignition end).

· Smoke & Toxicity Control: Requires evaluation of smoke density and toxic gas emissions to mitigate secondary hazard risks.

FMVSS 302 Test Protocol

1. Specimen Preparation

· Dimensions: 102 mm × 356 mm × actual thickness (max 13 mm). Thick materials exceeding 13 mm shall be trimmed.

· Quantity: Minimum 5-10 specimens per material direction. For anisotropic materials (e.g., textiles), test specimens cut along different orientations.

· Composite Handling: Laminated composites tested as-used; non-bonded materials tested separately.

2. Test Execution

· Flame Application: Apply standard burner flame to free end of specimen for 15 seconds, then remove ignition source.

· Data Recording: Monitor real-time burning duration, flame spread distance/rate, smoke characteristics, and residue morphology.

3. Compliance Determination

Evaluate flame retardancy through integrated parameters: burn rate, self-extinguishing time, and damage length, ensuring compliance with rigorous safety thresholds.

Global Harmonization of FMVSS 302

The standard demonstrates high interoperability with international counterparts:

· China GB 8410: Stricter burn rate requirement (≤100 mm/min) but shares similar methodology

· EU 95/28/EC: Focuses on vertical burn performance, complementing FMVSS 302

· ISO 3795: Applicable to agricultural/forestry vehicles with identical test principles

CASfire Technical Co.,Ltd
